NVIDIA RTX 4090 48GB

The RTX 4090 48GB is a consumer-grade GPU from nvidia's GeForce RTX 40 series, built on the Ada Lovelace architecture using the AD102 chip. Equipped with 48 GB of GDDR6X memory on a 384-bit bus, it delivers 1008.4 GB/s of bandwidth at 21.0 Gbps.

Launched on 11 Oct, 2022, the RTX 4090 48GB carried a starting price of $3999.

GPUs.net

Information
PlatformConsumer
ArchitectureAda Lovelace
GenerationGeForce RTX 40
Previous GenGeForce RTX 30
Next GenGeForce RTX 50
InterfacePCIe 4.0 x16
Core
NameAD102
FoundryTSMC
Process Node5 nm
Transistors76300 million
Die Size609.0 mm²
Density125.3 /mm²
GPU Core Config
Cores16384
TMUs512
ROPs176
SMs128
Tensor Cores512
RT Cores128
Memory
TechnologyGDDR6X
Size48 GB
Bus384 bit
Bandwidth1,008.4 GB/s
Speed21.0 Gbps

Information
Platform	Consumer
Architecture	Ada Lovelace
Generation	GeForce RTX 40
Previous Gen	GeForce RTX 30
Next Gen	GeForce RTX 50
Interface	PCIe 4.0 x16

Core
Name	AD102
Foundry	TSMC
Process Node	5 nm
Transistors	76300 million
Die Size	609.0 mm²
Density	125.3 /mm²

GPU Core Config
Cores	16384
TMUs	512
ROPs	176
SMs	128
Tensor Cores	512
RT Cores	128

Memory
Technology	GDDR6X
Size	48 GB
Bus	384 bit
Bandwidth	1,008.4 GB/s
Speed	21.0 Gbps

Clocks
Base clock2235 MHz
Boost Clock2520 MHz
Memory Clock1313 MHz
Power
16-pin1
TDP450 w
Recommended PSU850 w
Display
DisplayPort3
HDMI1
HDCP2.3
Dimensions
Slots2

Clocks
Base clock	2235 MHz
Boost Clock	2520 MHz
Memory Clock	1313 MHz

Power
16-pin	1
TDP	450 w
Recommended PSU	850 w

Display
DisplayPort	3
HDMI	1
HDCP	2.3

Dimensions
Slots	2

Models

GPU▲	Boost Clock▲	Slots▲	Length▲	Height▲	Width▲
