MSI GeForce GTX 275 LIGHTNING

Specs, info and data

The GPU Database

Featuring 270+ GPU models — and growing.

Database > GPUs > NVIDIA GTX 275 > MSI GeForce GTX 275 LIGHTNING

MSI GeForce GTX 275 LIGHTNING
N275GTX LIGHTNING
GPUs.net

Information
PlatformConsumer
ArchitectureTesla 2.0
GenerationGeForce 200
Previous GenGeForce 100
Next GenGeForce 300
InterfacePCIe 2.0 x16
Core
NameGT200B
FoundryTSMC
Process Node55 nm
Transistors1400 million
Die Size470.0 mm²
Density3.0 /mm²
GPU Core Config
Cores240
TMUs80
ROPs28
SMs30
Memory
TechnologyGDDR3
Size1.75 GB 0.875 GB
Bus448 bit
Bandwidth127.0 GB/s
Speed2.3 Gbps

Clocks
Base clock700 MHz 633 MHz
Shader Clock1404 MHz
Memory Clock1150 MHz 1134 MHz
Power
6-pin2
TDP220 w
Recommended PSU600 w
Display
HDMI1
DVI1
VGA1

Models

GPU▲	Shader Clock▲	Slots▲	Length▲	Height▲	Width▲
MSI GeForce GTX 275 LIGHTNING N275GTX LIGHTNING	-100.0%
