| Architecture | Ada Lovelace |
| Platform | Workstation |
| Generation | GeForce RTX 40 |
| Interface | PCIe 4.0 x16 |
| TDP | 130 w |
| Recommended PSU | 300 w |
| 8-pin | 1 |
| 16-pin | 1 |
| Base clock | 1500 MHz |
| Boost Clock | 2175 MHz |
| Memory Clock | 2250 MHz |
| Bus | 160 bit |
| Size | 20 GB |
| Technology | GDDR6 |
| RT Cores | 48 |
| Tensor Cores | 192 |
| Cores | 6144 |
| SMs | 48 |
| TMUs | 192 |
| ROPs | 64 |
| Name | AD104 |
| FP16 Tensor | 76.72 TFLOPS |
| FP32 | 31.72 TFLOPS |
| FP64 | 0.36 TFLOPS |
| Slots | 1 |
| Length | 245 mm |
| Height | 112 mm |
| Width | 20 mm |
| DisplayPort | 4 |
